Easy Gripper 1700

Easy Gripper

The Easy Gripper product range is designed to help professional tyre technicians in a multitude of conditions and situations. Implementing The Easy Gripper makes tyre handling faster and safer, while preventing damages to tyres, rims and equipment.

Capability

With a gripping range from Ø480 - 1.700 mm (19-67”) and a lifting capacity of 600 kg (1.320 lbs) the Easy gripper 1700 is developed to handle small and heavy OTR and AGRO tyre and wheel assemblies for the Aviation / Military / Mining / Ports / Industrial / OEM industry.

Forklifts

The Easy Gripper 1700 with the 90° tilt module is ideal for use on relatively small forklifts.

Electrical Stackers

Mounted on an electrical “walkie stacker” the Easy Gripper 1700 is ideal for operating at assembly lines or in workshops with limited space.

Standard features

• Unique and safe 3-point grip

  Prevents accidents.

  Prevents deformation of tyres.

  Prevents damages to tyres, rims and equipment.

• Integrated camera system for optimal view

  With automatic IR function in insufficient lighting conditions.

• 90° tilt, horizontal to vertical

• Precise rotation +/-25°

Turnkey solution

The Easy Gripper 1700 can be delivered as a turnkey solution that include +/- 80 mm side shift, slow drive mode and the control build in the tiller as standard features.

Optional accessories

• Quick Shift System
  Easy hook on and off. Shift between Gripper and forks in less than half a minute, by using the Fork Module and Hydraulic Multi Connection.

• Easy shift of gripping pipes for various purposes
  Flat top arm for limited tyre clearance.

• Customization on request

Video

Downloads

Contact us

Aviation

For logistic handling and moving of aircraft tyre and wheel assemblies. To and from stock and hangars. Mounting and demounting of wheels. With a safe grip and tilt and rotation functions.

Military

Ideal to change tyres and wheels in workshops but also outside - depending on the carrier, it is mounted on. Can be mounted as a quick shift attachment. Effectivity, safety, ergonomic improvements.

Mining

Ideal for road trains and other equipment with relatively small and heavy wheels. A great tool for service of tyres and wheels. Effectivity, safety, ergonomic improvements.

Ports

Easy Gripper 1700 can handle the smaller tyres and wheels on some RTG-cranes, Straddle Carriers, AGVs and other equipment. Where safety is important.

Industrial Trucks

Ideal to change tyres and wheels of trucks – especially in heavy industries with trucks with many and heavy wheels. Effectivity, safety, ergonomic improvements.

Workshops & OEM

To mount and demount tyres and wheels. A great and flexible tool for use at assembly lines. Very effective compared to overhead cranes and with improved safety and risk of internal damages.

Technical specifications

Technical Data

Weight: 420 kg (926 lbs)
Lifting capacity: 600 kg (1.323lbs)
Tyre diameter: 480 - 1.700 mm (19 - 67”)
Standard arms: Ø 89 x 600 mm (3,5 x 24”)
Attachment: ISO/FEM/ITA Class 2

Requirements to forklift or electrical stacker

Lifting capacity: Individual calculation
Electrical supply: 12/24 V / min 10A
Hydraulic: 1 double acting hydraulic valve
Pressure min-max: 110 - 250 bar (1.596 - 3.626 psi)
Return pressure: max. 10 bar (145 psi)
Flow: max. 40 l/min. (11 gal/min.)

Supporting tools and accessories

Even though the Easy Gripper is an incredible tyre handler / tyre manipulator, it can not do the entire tyre service job on it’s own. Therefore, we offer you following high-quality tools and accessories to support other parts of the tyre service processes.
